Operating the transmitter
MagicSwitch
The PROFI TX features 2 MagicSwitches.
A MagicSwitch is a logical switch which can be assigned and inverted like a real
control. It combines up to three switches (including the second MagicSwitch and
flight phases) in an AND function. Unused inputs are considered switched on. The
MagicSwitch is switched on when all switches that are assigned to it are switched on.
MagicSwitch output switches with a configurable delay. OFF and ON delays can be
configured separately.
Switches are assigned in the Setup > Assign.Switches > MagicSwitch menu
(see page 104).
To assign a MagicSwitch proceed as follows:
1. Move the input cursor to a switch.
2. Open the desired input field next to it.
3. Assign the desired switch using the central wheel or by operating the switch.
The switches MS1, MS2 (MagicSwitch) and FP1 to FP4 (flight phases)
cannot be assigned by operating a switch.
4. Set the switch to the ON position or select the ON position using the
REV/CLR button.
5. Close the input field.
