Nordson 3100V Series Customer Product Manual

Control
B 2-45
6. Parts
Using the lllustrated
Parts List
To order
parts,
call
the Nordson
Customer Service
Center
or
your
local
Nordson
representative.
Use this five-column
parts
list, and the
accompanying illustration,
to describe and locate
parts
correctly.
Numbers
in the ltem
column correspond to numbers
that identify
parts
in
illustrations following
each
parts
list. The
code NS
(not
shown) indicates
that a listed
part
is not illustrated.
A dash
(-)
is
used when the
part
number applies to
all
parts
in the illustration.
The six-digit number
in the Part
column is the Nordson
Corporation
part
number.
A series of
dashes
in
this column
(- -
-
-
-
-)
means
the
part
cannot be ordered
separately.
The Description
column
gives
the
part
name,
as
well
as its dimensions
and other characteristics
when appropriate. lndentions
show the
relationships between
assemblies,
subassemblies, and
pafis.
.
lf
you
order the
assembly, items 1
and
2 will
be included
.
lf
you
order item 1, item
2 will be included.
.
lf
you
order item 2,you will
receive item 2
only.
The number
in the
Quantity
column is the
quantity
required
per
unit,
assembly, or subassembly.
The code AR
(As
Required) is
used if the
part
number
is a bulk
item ordered in
quantities
or if
the
quantity per
assembly depends
on the
product
version
or model.
Letters in the Note
column refer
to notes at the
end of each
parts
list.
Notes contain important
information
about usage
and ordering.
Special
attention should
be
given
to notes.
Item
Part
Description
Quantity
Note
1
2
000 000
000 000
000 000
Assembly
.
Subassembly
.
.
Part
1
2
1
A
@ 2000
Nodson Corpdration
All righls reserved
4't-3000v
lssued
5/00
82EN-04-[3V-X-4XXVj-s
