RTD-SU\e
Hot
Melt Hose
13
3. lnstallation
WARNING: Allow only
qualified
personnelto
perform
maintenance,
repair, and troubleshooting tasks. Performing
activities not described in
this
manual may result in
personal
injury death, or equipment
damage.
NOTE: To install
a
new hose on
a new applicator
(in
which no hot melt
material has been melted), refer to the installation instructions in the
applicator technical manual.
NOTE: A hose connector ships with
each
hose. lt is needed when
installing a new hose on
a
new
applicator, or
when replacing
a
damaged
connector.
This section
provides
unpacking,
safety, and
installation
information
necessary for replacing
the Nordson RTD-style hoses.
A hose installation card is shipped with
every
hose. A copy of the card is
included in this section
(Figures
2
and 3). Contact
your
Nordson
representative to order extra copies.
Refer lo
Parts
and
Reference Data,
Section 6for the
part
number.
CAUTION: Make sure to unpack and unrollthe hose as shown r
in the illustrations on the carton to avoid kinking the hose's TFE
core. lf
the
core is kinked,
it will not return to shape, and the
hose will
fail
prematurely.
WARNING: Failure
to review the safety information in Safety,
Section 7, can result in
equipment damage,
personal
injury or
death. Before
performing
any
maintenance
on
any hose,
thoroughly
review
the safety section. Also, follow the specific
safety
precautions
contained in this section.
WARNING:
To ensure safe hose and
gun
operation,
do not use
non-conductive
pipe
compound
or tape on hose and
gun
hydraulic connections. Also,
make sure that the hose and
gun
are connected hydraulically
before
you
connect the hose
electrically
to the applicator.
WARNING: Burns
can occur from hot melt material that
remains in
the manifold connector or hose
after
draining. Make
sure not to
place
bare
hands underneath the connector or the
hose fitting.
Unpacking
Safety
Precautions
T
a
@
2000 Nordson Corporation
All rights
reserued
108 232E
lssued
'll00
Manual
45-2'l
