96
Chapter 5 Functions
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Image enhancement (“F9”)
This key changes the image enhancement modes. The three types and level of
the image enhancement should be set in advance. For the setup procedure, see
“Image enhancement (normal observation)” on page 226 and “Image
enhancement (NBI observation)” on page 250.
1. Press the “F9” key to display the current enhancement mode for a few
seconds.
2. During displaying the mode on the monitor, press the “F9” key to change the
enhancement mode (ex. A1, A3, etc.). The display window appears for a
few seconds.
Figure 5.43
Figure 5.44
