Olympus CV-180 User Manual

Chapter 5 Functions
149
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Displaying and entering scope information
1.
Press the “F2” key (see Figure 5.100). The scope information window
appears on the monitor for about 6 seconds (see Figure 5.101).
Figure 5.100
Figure 5.101
F2
ABC123
Mike Johnson
M 51
03/03/1954
12/12/2005
12:12:12
CVP: A4/4
D.F: 99
VCR
Ct: N Eh: A8
Z: x1.5
Pump
Media:
John Smith
Cardiac end of the stomach
2.8
1:Freeze
2:Iris
3:Enhance
4:Release
Serial No.
Channel
Distal End
Insertion Tube
Scope Name
:2500001
:2.8
:9.8
:9.8
GIF-H180
Forceps channel diameter
Scope switch assignment
Endoscope’s information
Displays the position to see the forceps
and the diameter of the instrument
channel.
Displays the functions assigned to the
scope switches.
Displays serial no., forceps channel diameter,
distal end diameter and insertion part diameter.
