Olympus CV-180 User Manual

148
Chapter 5 Functions
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
5.7 Scope information
Endoscopes equipped with the scope ID function incorporate a memory chip.
The memory chip stores data of the endoscope, and the data can be displayed
on the monitor. Some of the data can also be input from the video system center.
Table 5.18 shows the details of data stored in the memory chip.
• The memory chip is built with durability but may still be
damaged. If a memory chip is damaged, it becomes
incapable of backing up data. In such a case, please contact
Olympus.
• The following endoscopes are equipped with the scope ID
function;
 EVIS EXERA II series endoscopes
 EVIS EXERA 160 series or later endoscopes
(1 The items are not supported.)
 Some endoscopes of the VISERA series
Data item Details Input
Scope model Model name of the endoscope No
Serial number Serial number of the endoscope No
Comment Up to 20 characters can be entered. Yes
Cumulative uses Cumulated number of uses No
Checkup period Times of inspections
User can enter a number of 0 - 4095.
Yes
Service contract With or without a service contract No
Warranty date Warranty expiration date of the endoscope No
Customer name Person or hospital owning the endoscope
Up to 20 characters can be entered.
Yes
Customer ID ID number of the customer
User can enter up to 20 characters.
Yes
ID version The version number of the memory chip No
Channel diameter
1
Diameter of the endoscope channel
No
Distal end diameter
1
Outer diameter of the endoscope's distal end
No
Insertion tube
diameter
1
Outer diameter of the endoscope's insertion tube
No
Cumulative time
1
Cumulated time of uses
No
Table 5.18
