Chapter 8 Installation and Connection
179
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
8.7 Videocassette recorder (VCR)
When using the VCR remote terminal
For compatible video cassette recorders and cables to be used, see the table
below.
• When the SVO-9500MD is used together with the VTR
remote cable (MH-989), the SVO-9500MD has to be
equipped with the RS-232C interface board (SVBK-120). For
details, refer to the instruction manual for the interface board.
• When the SVO-9500MD is used together with the VTR
remote cable (MH-992), remote control is restricted to the
[Record] and [Pause] functions.
• For details, refer to the instruction manuals for the videotape
recorder and VTR remote cable.
• When the PDW-70MD or the PDW-75MD is used, SDI image
cable (MAJ-1464) is necessary with VTR remote cable (MAJ-
1568).
VCR
Cable
MH-989 MH-992 MAJ-906 MAJ-1568
DVO-1000MD (SONY)
DSR-20MD (SONY)
SVO-9500MD (SONY)
PDW-70MD (SONY)
PDW-75MD (SONY)
compatible, incompatible
Table 8.16
