Olympus CV-180 User Manual

216
Chapter 9 Function setup
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
9.3 User preset
The user preset menu sets the functions of this instrument for each individual
user, endoscope, etc., for up to 20 users. Each preset data has been set to the
factory defaults.
Basic operation of the user preset
1.
Press the “Shift” and “F2” key together (see Figure 9.12). The “User preset”
menu appears on the monitor (see Figure 9.13).
Figure 9.12
Figure 9.13
Button Function
Back Cancels the inputs, and returns to the endoscopic image.
Select Loads the selected user preset data on the video system center, then
returns to the endoscopic image.
Edit Edits the user preset data in the video system center.
Delete Deletes the user name and its data from the user name list.
Table 9.20
F2
Shift
