Chapter 5 Functions
129
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Videocassette recorder (VCR)
VCR can be operated using the keyboard. The following table shows the function
and the keys to operate.
Figure 5.78
1. Press the Image source button to change the image source.
• Press the “SCOPE” button to record the image.
• Press the “DV/VCR” button to playback the image.
2. Perform the VCR operation of recording or playback using the keys on the
keyboard (see Figure 5.78). “VCR” appears on the monitor during VCR
recording (see Figure 5.79).
After turning the DVO-1000MD ON and right after disk
insertion “Now Loading ...” is displayed. During this
initialization process images cannot be recorded.
Key Function
F10 ( )
Stops recording or playback.
F11 ( )
Pauses playback.
F12 ( )
Starts recording.
Print. screen ( )
Fast-rewinds the tape.
Scroll Lock ( )
Starts playback.
Pause ( )
Fast-forwards the tape.
Table 5.12
