144
Chapter 5 Functions
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Recording patient data into PC card
The patient data that is entered in the video system center can be saved on the
PC card. The recorded patient data can be transferred to another CV-180 using
the PC card.
Be sure to confirm that there is no necessary patient data on
the PC card which needs to be saved. The patient data on
the PC card will be deleted when new patient data is stored.
1. Insert the PC card into the PC card slot. The PC card status indicator lights
up in green.
Figure 5.96
2. Press the “Shift” and “F3” keys together to display “Patient Data” menu (see
Figure 5.97).
Figure 5.97
3. Click “Save” to record all patient data on the PC card.
