Chapter 9 Function setup
251
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Saving the user preset
This procedure finalizes and saves the user preset data.
Figure 9.46
1. Click “OK” in the user preset menu (see Figure 9.46). A confirmation
message appears on the monitor.
2. Click “N” to return to the user preset menu.
Click “Y” or press “Enter” to finalize and save the settings in the video
system center. The endoscopic image appears (see Figure 9.47).
Figure 9.47
• To cancel the data entered, click “Back” instead of “OK”. The
data entered are canceled and the display returns to the user
list menu.
• The functions are activated immediately after saving the user
preset data.
