206
Chapter 9 Function setup
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Image filing system
This operation sets the type of image filing system that is connected to the “PC”
terminal on the rear panel and the release time of the image filing system.
Figure 9.8
Click “PC” on the system setup menu. The setting items appear on the right side
of the window (see Figure 9.8).
Type of image filing system
1. Click “ ” of the “Type”. The types of image filing system appear in the pull-
down menu.
2. Click the system to use. The selected system is displayed.
Setting value Explanation
EndoWORKS The images can be recorded on the EndoWORKS system.
EndoALPHA The images can be recorded on the EndoALPHA system.
EndoBASE The images can be recorded on the EndoBASE system.
OFF The images cannot be recorded on any image filing system.
Table 9.11
Type of digital filing system
Release time of the digital filing system
Release time of EndoALPHA
To Next Page
