Chapter 8
Instal
lation and Connection
183
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
8.9
OLYMPUS flushing pump (OFP)
For connecting the Olympus flushing
pump
, use the cable listed
below.
For easy cable
connection, attach the cab
le color sheet to the cab
le (see Figure
8.22).
Figure 8.
22
Model
Product name
Note
MAJ-920
Pump remote cable
-
Table 8.19
PC REMOTE connector
MAJ-920
PC REMOTE
OFP
Remote control terminal
CV-180
4-pin connecto
r
14-pin connector
Cable color sheet
“PC REMOTE”
(blue)
190
192
