Chapter 9 Function setup
255
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Summary of settings
The following table shows the options of the user preset menu. The bold and
underscored options listed are the factory default settings.
Setup item Setting value Note
EXERA Scope switch Switch 1
Switch 2
Switch 3
Switch 4
[Freeze], [Release 1], [Release 2],
[Iris], [Enhance], [Contrast], [AGC],
[Image size], [VCR], [Capture],
[Stop watch], [Remove data], [Zoom],
[White balance], [Exposure area],
[Exposure (up)], [Exposure (down)],
[NBI], [OP.2], [OFP], [Light], [Arrow],
[PinP], [Shutter], [US freeze],
[Freeze mode], [Option], [None]
The same functions can be
assigned to more than one
switch.
The default settings are:
Switch 1: Freeze
Switch 2: Iris
Switch 3: Enhance
Switch 4: Release 1
Foot switch Switch 1
Switch 2
The same functions can be
assigned to more than one
switch.
The default settings are:
Switch 1: Release 1
Switch 2: Release 2
VISERA Scope switch Switch 1
Switch 2
Switch 3
Switch 4
[Freeze], [Release 1], [Release 2],
[Iris], [Enhance], [Contrast], [AGC],
[Image size], [VCR], [Capture],
[Stop watch], [Remove data], [Zoom],
[White balance], [Exposure area],
[Exposure (up)], [Exposure (down)],
[NBI], [OP.2], [OFP], [Light], [Arrow],
[PinP], [Shutter], [US freeze],
[Freeze mode], [Option], [None]
The same functions can be
assigned to more than one
switch.
The default settings are:
Switch 1: Release 1
Switch 2: Enhance
Switch 3: VCR
Switch 4: Freeze
Foot switch Switch 1
Switch 2
The same functions can be
assigned to more than one
switch.
The default settings are:
Switch 1: Release 1
Switch 2: Release 2
Release Release
setting
Release 1 [CVP], [PC card], [Digital file] Devices to be operated by
“Release1” and “Release 2”.
Release 2 [CVP], [PC card
], [Digital file]
Picture [SHQ
], [HQ], [SQ], [TIFF] Recording format for PC
card
Freeze
mode
[Field
], [Frame] Freeze method
Table 9.53
