Quantum QXS G2 Series User Manual

152 QXS G2 Hardware Installation and Maintenance Guide
2U12 Expansion Chassis CRUs (Rear)
Figure 113 provides the location of the 2U12 expansion chassis CRUs (rear) with two expansion IOMs
installed.
Figure 113 2U12 Expansion Chassis CRUS (Rear) with Two Expansion IOMs
Tabl e 3 9 provides a list of CRUs in the 2U12 expansion chassis (rear) for Figure 113.
NOTE: Figure 124 on page 162 provides a representative example of the controllers used in the
RAID chassis.
Figure 125 on page 163 provides a representative example of the IOMs used in the expansion chassis.
The QXS-G2-312, QXS-G2-324, QXS-G2-412, QXS-G2-424, and QXS-G2-484 use the same identical
IOMs.
2U24 RAID Chassis/Expansion Chassis CRUs
This section provides the following information:
Chassis Chassis (sheet metal chassis that is configurable as a RAID or expansion chassis)
Rail Kit Rail kit (variable attachment options)
2U rack mount kit, shelf, short, all HW
Cable
Kits
Cable kit [Cable package: standard HD mini-SAS (SFF-8644) to HD mini-SAS (SFF-8644)]
Cable kit [Cable package: standard HD mini-SAS (SFF-8644) to mini-SAS (SFF-8088)]
Cable kit [Cable package: USB Type B; CLI (USB)]
Power
Cord
AC power cord compatible with AC PSU(s)
Ta b l e 3 8 2U12 RAID Chassis CRUs (Front)
Item Chassis Component Description
1
2
3
4
Ta b l e 3 9 2U12 Expansion Chassis CRUs (Rear)
Item Chassis Component Description
1 Expansion IOM A
2 Expansion IOM B
3 PSU0
4 PSU1
