216 QXS G2 Hardware Installation and Maintenance Guide
QXS 5U Chassis Dimensions
Tabl e 4 9 provides the 5U chassis dimensions.
QXS 2U/5U Chassis Weights
Tabl e 5 0 provides the chassis weights for the 2U12, 2U24, and 5U84 chassis.
Ta b l e 4 9 QXS 5U Chassis Dimensions
Specification Metric Unit Imperial Unit
Overall chassis height (5U) 222.3 mm 8.75 in
Width across mounting flange (located on front of chassis) 483 mm 19.01 in
Width across body of chassis 444.5 mm 17.50 in
Depth from face of mounting flange to back of chassis body 892.2 mm 35.12 in
Depth from face of mounting flange to rearmost chassis extremity 974.7 mm 38.31in
Depth from face of Ops panel to rearmost chassis extremity 981 mm 38.62 in
Note: The 5U84 uses 3.5" LFF disks in the DDIC carrier. It can also use 2.5" SFF disks with 3.5" adapter in the
DDIC.
Ta b l e 5 0 QXS 2U/5U Chassis Weights
CRU/Component 2U12 (kg/lb) 2U24 (kg/lb) 5U84 (kg/lb)
Storage chassis (empty) 4.8/10.56 4.8/10.56 64/141
Disk drive carrier 0.9/1.98 0.3/0.66 0.8/1.8
Dummy disk drive carrier (air management sled) 0.05/0.11 0.05/0.11 -
2U Power Supply Unit (PSU) 3.5/7.7 3.5/7.7 -
5U Power Supply Unit (PSU) - - 2.7/6.0
5U Fan - - 1.4/3.0
Controller (module in RAID chassis) 2.6/5.8 2.6/5.8 2.6/5.8
Expansion IOM (module in expansion chassis) 1.5/3.3 1.5/3.3 1.5/3.3
RAID chassis (fully populated with modules: maximum
weight)
32/71 30/66 135/298
Expansion chassis (fully populated with modules:
maximum weight)
28/62 25/55 13/287
Note 1: Weights shown are nominal, and subject to variances.
Note 2: 2U rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate chassis weight. 5U rail kits
add significantly more weight.
Note 3: Weights may vary due to different power supplies, controllers/expansion IOMs, and differing
calibrations between scales.
Note 4: Weights may vary due to actual number and type of drives (SAS or SSD) and air management modules
installed.
