Quantum QXS G2 Series User Manual

24 QXS G2 Hardware Installation and Maintenance Guide
NOTE: Figure 27 displays the front of the drawer on the left side of the illustration. The back of the
drawer is on the right side of the illustration.
Figure 27 5U84 RAID or Expansion Chassis Drive Slots
5U84 RAID Chassis (Rear View/Two CNC Controllers)
Figure 28 on page 25 provides an illustration of the 5U84 RAID chassis rear view with two CNC
controllers (FC/iSCSI, 4-ports) installed.
NOTE: The 5U84 RAID chassis supports attachment of expansion chassis for adding storage.
2
1
3
4
0/42
2/44
1/43
3/45
4/46
5/47
6/48
7/49
8/50
9/51
10/52
11/53
12/54
13/55
14/56
15/57
16/58
23/65
18/60
19/61
20/62
21/63
22/64
41/83
17/59
25/67
26/68
27/69
28/70
29/71
30/72
31/73
24/66
37/79
38/80
35/77
39/81
33/75
34/76
36/78
40/82
32/74
1
Drawer 0/1 Front
2
Drawer 0/1 Left Side
3
Drawer 0/1 Rear (slides into chassis)
4
Drawer 0/1 Right Side
