SFP Option for CNC Ports 233
4 Slide the SFP into the target CNC port until it locks securely into place.
5 Flip the actuator closed (sweep up or down) according to its position in canister slot 0A or 0B.
The installed SFP should look similar to the position shown in the right detail view above.
6 When ready to attach to the host, obtain and connect a qualified fiber-optic interface cable into
the duplex jack at the end of the SFP connector.
Verify Component Operation
View the CNC port Link Status/Link Activity LED on the controller face plate. A green LED indicates
that the port is connected and the link is up:
• For FC SFPs, see Figure 47 on page 42.
• For 10GbE iSCSI SFPs, see Figure 47 on page 42.
• For 1Gb iSCSI SFPs, see Figure 48 on page 44
NOTE: To remove an external SFP connector, perform the installation steps in reverse order relative
to what is described in Install SFP Transceiver on page 232.
