Technical Specifications 215
Chapter 7
Technical Specifications
This chapter provides the following information:
• QXS 2U/5U Chassis Dimensions
• QXS 2U/5U Chassis Weights
• QXS 2U/5U Environmental Requirements
• QXS 2U/5U PSU Specifications
QXS 2U/5U Chassis Dimensions
This section contains the following information:
• QXS 2U Chassis Dimensions
• QXS 5U Chassis Dimensions
QXS 2U Chassis Dimensions
Tabl e 4 8 provides the 2U chassis dimensions.
Ta b l e 4 8 QXS 2U Chassis Dimensions
Specification Metric Unit Imperial Unit
Overall chassis height (2U) 87.9 mm 3.46 in
Width across mounting flange (located on front of chassis) 483 mm 19.01 in
Width across body of chassis 443 mm 17.44 in
Depth from face of mounting flange to back of chassis body 576.8 mm 22.71 in
Depth from face of mounting flange to rearmost chassis extremity 602.9 mm 23.74 in
Depth from face of Ops panel to rearmost chassis extremity 629.6 mm 24.79 in
Note 1: The 2U24 chassis uses 2.5" SFF disks.
Note 2: The 2U12 chassis uses 3.5" LFF disks.
