Quantum QXS G2 Series User Manual

System Overview 31
2U24 Chassis Ops Panel
Figure 36 provides a front view of the 2U24 chassis with the ops panel.
Figure 36 2U24 Chassis Ops Panel
2U12 and 2U24 Ops Panel Functions
An integral part of the chassis, the Ops panel is not replaceable on site. The Ops panel provides the
functions shown in the illustration below and listed in the table. See also 2U Chassis Ops Panel LEDs
on page 118.
Figure 37 2U Chassis Ops Panel Functions
1
Ops Panel
2
2U12 Chassis
Note: Drives are numbered from 0-11 (12 drives).
01
2345
6
78
9
10 11 12 13 14 15
16 17
18
19 20
21 22
23
2
1
1
Ops Panel
2
2U24 Chassis
Note: Drives are numbered from 0-23 (24 drives).
LED Status
1
Unit Identification Display Green: Seven segment display: chassis sequence
2
Identity Blue: Power On (5s) test state
3
Module Fault Constant or blinking amber: fault present
3
4
5
2
1
