SP Mode Service Tables
J012/J013/J014 5-46 SM
5.3.2 GROUP 1000
Main Scan, Sub Scan Registration
1000 REG:FD:NORM:F Adjust Sub Scan Registration (Normal Paper)
Use this SP code to adjust writing in the sub scan registration for normal paper.
Do this setting when registration does not match the direction of paper feed
selected in the user image adjustment menu. [-128 to +127/FA/1/0.1 mm]
1001 REG:TR1:NORM:F Adjust Main Scan Registration (Normal Paper: Tray 1)
Use this SP code to adjust writing in the main scan direction for normal paper
loaded in Tray 1. Do this setting when registration does not match the image
start position on the user image adjustment menu. [-128 to +127/FA/1/0.1 mm]
1002 REG:TR2:NORM:F
Adjust Main Scan Registration (Tray 2: Normal Paper:
FA)
Use this SP code to adjust writing in main scan direction for normal paper
loaded in Tray 2. Do this setting when registration does not match the image
start position on the user image adjustment menu.
[-128 to +127/FA/1/0.1 mm]
1003 REG:MAN:NORM:F
Adjust Main Scan Registration (Bypass: Normal
Paper: FA)
Use this SP code to adjust writing in the main scan direction for normal paper
loaded in the bypass tray. Do this setting when registration does not match the
image start position on the user image adjustment menu.
[-128 to +127/FA/1/0.1 mm]
1004 REG:FD:GLOS:F Adjust Sub Scan Registration (Glossy Paper: FA)
Use this SP code to adjust writing in the the sub scan registration for glossy
paper. Do this setting when registration does not match the direction of paper
feed selected in the user image adjustment menu.
[-128 to +127/FA/1/0.1 mm]
