J012/J013/J014 7-10 SM
7.1.5 TARGET YIELDS
General
Print Cartridges Starter Black (K) 400 sheets
Color (Y, M,
C)
400 sheets
Standard Black (K) 1,500 sheets
Color (Y, M,
C)
1,000 sheets
Page / Job
Expected
Replacement
Period
Yield of
Ink Collector Unit
1 P/J 22.1 months 16.6K prints
2 P/J 23.1 months 17.3K prints
3 P/J 23.3 months 17.5K prints
Ink Collector Unit
Conditions:
5% A4 Chart,
APV 750 sheets
See NOTE 1 below:
24 P/J 24.0 months 18.0K prints
Estimated Service Life
3 Years (average), 5 Years (maximum)
 Duty: 150 K
 Monthly print volume: 10 K sheets
Target Yields calculated for:
 Continuous printing on A4 (8.5”x11”) with 5% of the standard color chart at standard
temperature and humidity.
 Yield numbers may change depending on the environmental conditions, amount of
coverage on pages, and the number of print head cleanings/flushing that has been
done.
NOTE1: Although the Ink Collector was provided as a service part on the predecessor
model, for these models, it will be provided as a consumable (supply product).
Sales Item Number: Ricoh 405662, Savin, 405662, Lanier 040-5662
⇒
⇒
Rev. 04/2008
