SP Mode Service Tables
SM 5-87 J012/J013/J014
Service
Tables
Display Count: Mist Counter for Automatic Cleaning
7204 MIST CNT:T1 Print Head Tank 1
7205 MIST CNT:T2 Print Head Tank 2
7206 MIST CNT:T3 Print Head Tank 3
7207 MIST CNT:T4 Print Head Tank 4
7208 MIST CNT:T5 Print Head Tank 5
7209 MIST CNT:T6 Print Head Tank 6
Use this SP to display the number of times that the swing plate of the left Ink
Collector tank has made contact with the carriage.
Display Count: Paper Dust Counter for Automatic Cleaning
7210 FEED:CNT:H1 Print Head Tank 1
7211 FEED:CNT:H2 Print Head Tank 2
7212 FEED:CNT:H3 Print Head Tank 3
7213 FEED:CNT:H4 Print Head Tank 4
Use this SP to display the current reading of the ink mist counter that determines
when to execute automatic cleaning.
Display Count: Cap Off Time for Automatic Print Head Cleaning
7214 DECAP TIME
Use this SP to display the de-capping time used to determine whether automatic
cleaning is executed after the printer returns from idle mode.
