SP Mode Service Tables
J012/J013/J014 5-54 SM
Charge Width Setting Mj4: Duplex (DFU)
1156 CHG:W2:EDGE:13 LE/TE: Mj4: ID1
1158 CHG:W2:EDGE:14 LE/TE: Mj4: ID2
1160 CHG:W2:EDGE:15 LE/TE: Mj4: ID3
1162 CHG:W2:EDGE:16 LE/TE: Mj4: ID4
1157 CHG:W2:MIDL:13 MIDL: Mj4: ID1
1159 CHG:W2: MIDL:14 MIDL: Mj4: ID2
1161 CHG:W2: MIDL:15 MIDL: Mj4: ID3
1163 CHG:W2: MIDL:16 MIDL: Mj4: ID4
Calibrate Humidity/Temperature for Duplex
1164 CHG:HUMI:B Calibrate Humidity Setting for Duplex
Use this SP to calibrate the temperature/humidity sensor for humidity readings
during duplex printing. Do this SP to update the charge pitch table for duplex
printing. This SP setting is linked to the humidity steps in the charge pitch tables
(SP1200 to SP1231).
[-128 to +127/0/1/0.1%]
1165 CHG:TEMP:B Calibrate Temperature Setting for Duplex
Use this SP to calibrate the temperature readings for duplex printing. Do this SP
to update the charge pitch table for duplex printing. This SP setting is linked to the
temperature steps in the charge pitch tables (SP1200 to SP1231).
[-128 to +127/0/1/0.1%]
