PM Table
SM 2-1 J012/J013/J014
Preventive
Maintenance
2. PREVENTIVE MAINTENANCE
2.1 PM TABLE
There are no PM parts in this machine.
2.1.1 SERVICE CALL PROCEDURES
The "Service Call Procedures" listed below should be done by the service technician. For
more details about how to do these procedures, please refer to "Cleaning Procedures" in
Section 3.
Description At Service Call, or As Required
External Covers Damp cloth.
Feed Roller Damp cloth. Release the feed clutch lock. Rotate the roller freely
as you clean it.
Flushing Unit Gate Dry cloth. Always remove the ink that has hardened around the
flushing gate when you replace the waste ink tank. To remove
hardened ink, you may need to use a small screwdriver or similar
tool.
Friction Pad Damp cloth. This is the cork friction pad on the front edge of the
standard paper cassette.
Maintenance Unit Dry cloth. Always use a tightly wrapped dry cloth to remove the ink
that has hardened around the suction cap and wiper blade when
you replace the waste ink tank.
Printer Operation,
Print Quality
Print a Nozzle Check Pattern and check the results. Clean the
print heads if necessary. For more, see "Image Adjustment" in
section "3. Replacement and Adjustment.”
Transport Belt Damp cloth. Then dry cloth.
Important: To protect the surface of the transport belt, never use
alcohol or any other type of organic solvent.
