SP Mode Service Tables
SM 5-61 J012/J013/J014
Service
Tables
Print Head Temperature Thresholds
1300 HTEMP:H:STOP Trigger Shutdown: Standby, Printing
1301 HTEMP:H:JUDG Trigger Shutdown: Power On
1302 HTEMP:H:RCVR Recovery After High Temp Shutdown
1303 HTEMP:L:RCVR Recovery After Low Temp Shutdown
1304 HTEMP:L:JUDG Trigger Shutdown: Power On
1305 HTEMP:L:STOP Trigger Shutdown: Standby, Printing
Use this SP to set the threshold for the operating temperature range of the print
head.
[0 to 65535/0/1/0.1
o
C
Ambient Temperature Thresholds
1306 ETEMP:H:STOP High Temperature to Trigger Shutdown: Standby, Printing
1307 ETEMP:H:JUDG High Temperature to Trigger Shutdown: Power On
1308 ETEMP:H:RCVR Recovery After High Temp Shutdown
1309 ETEMP:L:RCVR Recovery After Low Temp Shutdown
1310 ETEMP:L:JUDG Low Temperature to Trigger Shutdown: Power On
1311 ETEMP:L:RCVR Low Temperature to Trigger Shutdown: Standby, Printing
Use this SP to set the threshold for the operating humidity range of the print head.
[0 to 65535/0/1/0.1
o
C
