SP Mode Service Tables
SM 5-55 J012/J013/J014
Service
Tables
Charge ID Tables: Mj1
1200 CHG:PITCH:A1 Mj1: Less Than 10% Lookup Table
1201 CHG:PITCH:A2
Mj1: 10% → 25% Lookup Table
1202 CHG:PITCH:A3
Mj1: 25% → 35% Lookup Table
1203 CHG:PITCH:A4
Mj1: 35% → 45% Lookup Table
1204 CHG:PITCH:A5
Mj1: 45% → 55% Lookup Table
1205 CHG:PITCH:A6
Mj1: 55% → 65% Lookup Table
1206 CHG:PITCH:A7
Mj1: 65% → 75% Lookup Table
1207 CHG:PITCH:A8 Mj1: More than 75% Lookup Table
Use this SP to configure the charge ID table for printing on normal paper in High
Speed (Draft) mode. Do this SP when mist build-up on the paper in use is
clogging the print head nozzles.
This setting is linked to the charge pitch settings (SP1100 to 1107, SP1133 to
1139).
[0 to 0xffff ffff/0/1/---]
For more details, please refer to Section 4 "Transport Belt Charge Adjustments.”
