Ricoh J012 User Manual

SP Mode Service Tables
SM 5-71 J012/J013/J014
Service
Tables
Maintenance, Replacement
5007 WASHING Execute Auto Washing
Executes the automatic flushing procedure.
5100 INK DISCHARGE Purge Maintenance: Right Vent
For Future Use.
Moves the carriage in order to access the right air vent for cleaning.
5101 CARRIAGE CHANGE Set Printer in Carriage Replace Mode
Use this SP to reset the print head rank setting after print head replacement and
to re-initialize the initial filling counter.
Carriage Replacement
1. Enter the print head rank (wave) of
 Print head 1.
 Print head 2.
 Print head 3.
 Print head 4.
2. Enter the print head rank (voltage) of
 Print head 1.
 Print head 2.
 Print head 3.
 Print head 4.
Initial Fill Counter Reset
1. Turn the printer off.
2. After executing this menu, turn the printer on to start initial filling of the
print head tanks.
3. After executing this menu, the carriage adjustment mode can be
executed.
