SP Mode Service Tables
J012/J013/J014 5-56 SM
Charge ID Tables: Mj2
1208 CHG:PITCH:B1 Mj2: Less Than 10% Lookup Table
1209 CHG:PITCH:B2
Mj2: 10% → 25% Lookup Table
1210 CHG:PITCH:B3
Mj2: 25% → 35% Lookup Table
1211 CHG:PITCH:B4
Mj2: 35% → 45% Lookup Table
1212 CHG:PITCH:B5
Mj2: 45% → 55% Lookup Table
1213 CHG:PITCH:B6
Mj2: 55% → 65% Lookup Table
1214 CHG:PITCH:B7
Mj2: 65% → 75% Lookup Table
1215 CHG:PITCH:B8 Mj2: More than 75% Lookup Table
Use this SP to configure the charge ID table for printing on any paper in any mode
except: normal paper in High Speed (Draft) mode and glossy paper in High
Quality mode. Do this SP when mist build-up on the paper in use is clogging the
print head nozzles during printing with any paper in any mode, except: normal
paper in High Speed (Draft) mode and glossy paper in High Quality mode. This
setting is linked to the charge pitch settings (SP1108 to 1115, SP1140 to 1147).
[0 to 0xffff ffff/0/1/---]
For more details, please refer to Section 4 "Transport Belt Charge Adjustments.”
