SP Mode Service Tables
SM 5-83 J012/J013/J014
Service
Tables
Display Count: Air Detected in Print Head Tank After During
Maintenance After Purge
7132 AIR CNT:A:T1 Print Head Tank 1
7133 AIR CNT:A:T2 Print Head Tank 2
7134 AIR CNT:A:T3 Print Head Tank 3
7135 AIR CNT:A:T4 Print Head Tank 4
7136 AIR CNT:A:T5 Print Head Tank 5
7137 AIR CNT:A:T6 Print Head Tank 6
Use this SP to display the number of times air was detected by the air sensor in a
print head tank during automatic print head maintenance triggered by the printer
remaining idle.
Display Count: Automatic Cleanings Between Page Prints
7138 ACL CNT:P:H1 Print Head 1
7139 ACL CNT:P:H2 Print Head 2
7140 ACL CNT:P:H3 Print Head 3
7141 ACL CNT:P:H4 Print Head 4
Use this SP to display the number of automatic print head cleanings between
page prints while print jobs were executing.
