SP Mode Service Tables
SM 5-77 J012/J013/J014
Service
Tables
No. Meaning No. Meaning
1 to 4 Not Used 11 Cyan Ink Cartridge: Re-Fill
5 Yellow Ink Cartridge: Re-Fill 12 Cyan Ink Cartridge: Brand New
6 Yellow Ink Cartridge: Brand New 13 Cyan Ink Cartridge: Set Sensor
7 Yellow Ink Cartridge: Set 14 Black Ink Cartridge: Re-Fill
8 Magenta Ink Cartridge: Re-Fill 15 Black Ink Cartridge: Brand New
9 Magenta Ink Cartridge: Brand New 16 Black Ink Cartridge: Set Sensor
10 Magenta Ink Cartridge: Set
Input Check: Ink Cartridge Levels
5412 INPUT CHK RES:Y Yellow Ink Cartridge
5413 NPUT CHK RES:M Magenta Ink Cartridge
5414 NPUT CHK RES:C Cyan Ink Cartridge
5415 NPUT CHK RES:K Black Ink Cartridge
Use this SP to display the amount of ink that remains in each ink cartridge.
Units: %
Input Check: Ink Collector Unit Sensor
5416 INPUT CHK WASTE Current Analog Reading
Use this SP to display the analog reading of the Ink Collector tank sensor.
