SP Mode Service Tables
SM 5-69 J012/J013/J014
Service
Tables
Set Amount for Standard Ink Coverage
3200 COVER:REG:B Black: 319 u1
3201 COVER:REG:M Magenta: 273 u1
3202 COVER:REG:C Cyan: 187 u1
3203 COVER:REG:Y Yellow: 276 u1
Use this SP to adjust the standard amount of ink to be applied for full coverage
areas.
[0 to 65535/0/1/um]
Gamma: K, C, M, Y
3300 GAMMA:K
3301 GAMMA:C
3302 GAMMA:M
3303 GAMMA:Y
This SP prints the Gamma Adjustment Chart and allows you to set the optimum
settings for gamma adjustment. The optimum settings are printed on a decal
attached to the carriage.
5.3.5 GROUP 4000
Not used.
