SP Mode Service Tables
J012/J013/J014 5-58 SM
1231 CHG:PITCH:D8 Mj4: More than 75% Lookup Table
Use this SP to configure the charge ID table for printing on glossy paper in Quality
mode. Do this SP when mist build-up on glossy paper in use is clogging the print
head nozzles. This setting is linked to the charge pitch settings (SP1124 to 1131,
SP1156 to 1163).
[0 to 0xffff ffff/0/1/---]
Set Charge Area 1
1232 CHG:AREA1:OHP Set Charge of Area 1 for LE/TE: OHP
Use this SP to set the size of the leading and trailing edges of transparencies
(OHP). Do this setting when you want to adjust pitch amount of the charge
applied to the leading and trailing edge of transparencies for printing. The areas
of the leading and trailing edges is shown below.
[0 to 0xffff ffff/0/1/---]
1233 CHG:AREA1:F
Set Charge of Area 1 for LE/TE: Simplex: Any Other Than
OHP
Use this SP to set the size of the leading and trailing edges for the 1st side of any
paper except transparencies (OHP). Do this setting when you want to adjust pitch
amount of the charge applied to the leading and trailing edges on the 1st side any
paper except transparencies. The areas of the leading and trailing edges is
shown below.
[0 to 0xffff ffff/0/1/---]
1234 CHG:AREA1:B
Set Charge of Area 1 for LE/TE: Duplex: Any Other Than
OHP
Use this SP to set the size of the leading and trailing edges for the 2nd side
(duplex printing) of any paper except transparencies (OHP). Do this setting when
you want to adjust pitch amount of the charge applied to the leading and trailing
edges on the 2nd side any paper except transparencies for duplex printing. The
areas of the leading and trailing edges are shown below.
[0 to 0xffff ffff/0/1/---]
