Paper Feed, Transport, Paper Exit
SM 6-59 J012/J013/J014
Detailed
Description
6.8 PAPER FEED, TRANSPORT, PAPER EXIT
6.8.1 OVERVIEW
1 Transport Belt Unit
2 HVPS (High Voltage Power Supply)
3 Vertical Encoder
4 Vertical Encoder Sensor
5 Vertical Motor
