SP Mode Service Tables
J012/J013/J014 5-76 SM
Input Check: Air
5405 INPUT CHK AIR1 Tank 1: Analog
Use this SP to display the analog reading of the air sensor in print head tank 1.
5406 INPUT CHK AIR2 Tank 2: Analog
Use this SP to display the analog reading of the air sensor in print head tank 2.
5407 INPUT CHK AIR3 Tank 3: Analog
Use this SP to display the analog reading of the air sensor in print head tank 3.
5408 INPUT CHK AIR4 Tank 4: Analog
Use this SP to display the analog reading of the air sensor in print head tank 4.
5409 INPUT CHK AIR5 Tank 5: Analog
Use this SP to display the analog reading of the air sensor in print head tank 5.
5410 INPUT CHK AIR6 Tank 6: Analog
Use this SP to display the analog reading of the air sensor in print head tank 6.
Input Check: Ink Cartridge Set Sensors
5411 INPUT CHK CART Display Status of Ink Cartridge Set Sensors
Use this SP to display the status of the cartridge set sensor. The status of each
sensor is assigned to a column in the 2nd line of the operation panel display as
shown below.
