Cutting data can be grouped into layers by color or type of cutting line, and you can set parameters as
cutting conditions and the cutting mode for each layer. The cutting output order can also be changed
manually or automatically.
Configuring the Cutting Conditions Based on the Color of Cutting Lines
You can set cutting conditions for each layer. Because objects drawn using vector lines are also group-
ed into layers, check whether a layer includes cutting lines while setting the cutting conditions.
Procedure
1. Start GreatCut-R.
2. Display cutting data, which includes the cutting lines, on the GreatCut-R work screen.
• GreatCut-R format file:
Select the cutting data from [File]>[Open], and then click [Open].
• Other files:
Select the cutting data from [File]>[Import], and then click [Open].
MEMO
CorelDRAW format files cannot be imported into GreatCut-R. Open the target cutting data in CorelDRAW and
click
on the menu bar.
3. Right-click on any layer in the Layer window.
The [Layer Settings] window appears. If the Layer window is not displayed, turn on [Win-
dow]>[Layer].
4. Click the layer with the cutting lines used in the cutting data and configure the layer's output set-
tings.
Clicking [Output] or [Color] switches the display of the [Layer Settings] window.
Setting item
Settings Notes
[Information] Enter the layer name by combining the cutting type, col-
or number, etc.
*1
Setting Up Cutting by Layer
Using GreatCut-R 99
To Next Page
