Preventing Positioning Errors by Setting Material Feeding
Before starting cutting, set up the machine so that the material length necessary for cutting data is
fed forward automatically beforehand, stabilizing the material feeding and preventing positioning er-
rors. Also, feeding the material forward at the speed it is cut reduces the load on the motor. Be sure
to set feeding for materials that require it.
IMPORTANT
This function is disabled when the [Single] mode is selected for material size measurement.
MEMO
Materials that Require Feeding
• Roll material
• Long, flat material that is longer than 1.6 m (63.00 in.)
Procedure
1. Press [MISC].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
The screen shown below appears.
Auto Unrolled Media
Select: OK:ENTER
2. Press [ENTER].
The current setting is displayed.
3. Press [▲] or [▼] to switch to "Enabled".
4. Press [ENTER].
The screen shown below appears.
Pre-feed Length
Select: OK:ENTER
5. Press [ENTER].
The current setting is displayed.
Pre-feed 600 mm
N:OFFLINE OK:ENTER
6. Press [▲] or [▼] to set the material length required for the cutting data.
It is a good idea to set a value that is about 500 mm (19.69 in.) longer than the required mate-
rial length.
7. Press [ENTER].
The screen shown below appears.
Pre-feed Times
Select: OK:ENTER
8. Press [ENTER].
The current setting is displayed.
Settings for Preventing Problems
130 Other Operations and Settings
