Replacing the Blade Protector
If cutting is performed when the amount of blade extension or the blade force is not adjusted appro-
priately, the tip of the blade may pierce the carrier paper and scratch the blade protector. Replace
the blade protector with the cutting pad supplied with this machine.
CAUTION
Be sure to perform operations as specified by the instructions above, and never
touch any area not specified in the instructions.
Sudden movement of the machine may cause injury or burns.
Procedure
1. Remove the material.
Raise the lever.
2. Move the cutting carriage to the edge.
3. Remove the blade protector.
4. Affix the cutting pad where the blade protector was, ensuring that it is straight.
Replacing Consumable Parts
140 Cleaning and Replacing Consumable Parts
