To obtain high-quality cutting results, carry out a cutting test to check the cutting quality for the ma-
terial before you perform the actual cutting. Find the appropriate settings by checking the results.
Procedure
1. Load the material and measure its size.
P. 21 "Loading the Material"
2. Press [ON/OFF LINE] to switch to offline mode.
3. Press [CUT TEST].
4. Select a cutting test pattern.
Normally you select "Arrow", but if you are cutting a thick material, select "Cross".
(1) Press [◀] or [▶] to display the screen shown below.
Pattern Setting
Select: OK:ENTER
(2) Press [ENTER].
The current pattern is displayed.
Pattern: Arrow
Change: OK:ENTER
(3) Press [▲] or [▼] to select a cutting test pattern.
(4) Press [ENTER].
5. Change the scale of the pattern size.
This is set to 100% by default. Using a larger pattern size makes it easier to check the cutting
test result.
(1) Press [◀] or [▶] to display the screen shown below.
Ratio Setting
Select: OK:ENTER
(2) Press [ENTER].
The current scale of the pattern size is displayed.
Ratio: 100%
Change: OK:ENTER
(3) Press [▲] or [▼] to select the scale of the pattern size.
The size can be scaled from 1x to 4x.
(4) Press [ENTER].
6. Press [◀] or [▶] to display the screen shown below.
Square Cut
Select: OK:ENTER
7. Press [ENTER].
8. Press [◀], [▶], [▲] or [▼] to move the cutting carriage to the appropriate location (cutting test
start position).
9. Press [ENTER].
The test pattern is cut. When the cutting test finishes, the screen shown below is displayed.
Continous Square Cut
N:ONLINE OK:ENTER
Performing a Cutting Test
Preparations before Cutting Output 37
To Next Page
