The USB cable tie does not need to be removed and can be kept fixed onto the machine. When reat-
taching the USB cable tie after removing it, refer to the Setup Manual.
Procedure
1. Pull out the tip of the USB cable tie from the tie head.
2. Push the cable tie pin in and pull forward.
3. Loosen the cable tie.
Removing the USB Cable Tie
Operations When Moving the Unit 169

Roland Camm-1 GR2-540 Specifications

General

Connectivity	USB 2.0, Ethernet
Cutting Method	Media-moving method
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Power Requirements	AC 100 to 240 V ±10%, 50/60 Hz
Cutting Width	54 inches
Maximum Cutting Speed	1, 485 mm/s
Software Resolution	0.025 mm/step
Weight	187 lbs
Usable Tools	Cutting blade, plotting pen
Distance Accuracy	±0.2% or 0.3 mm (0.012 in), whichever is greater
Repeatability Accuracy	±0.1 mm
Alignment Accuracy for Print & Cut	±0.04 inches
Operating Temperature	41-95°F (5-35°C)
Operating Humidity	35 to 80% RH (non-condensing)
Weight (with stand)	187 lbs
Blade Type	Roland CAMM-1 series blades
Resolution	0.025 mm/step
