Roland Camm-1 GR2-540 User Manual

Important Notes on Using Pinch Rollers
When using the pinch rollers for setting up the material, be sure to follow the precautions below. Keep
the lever raised when the pinch rollers are not in use.
• Be sure to raise the pinch rollers before moving them. Use the lever to raise or lower the pinch
rollers.
• To move a pinch roller, push the pinch roller support ( ).
MEMO
Push the grip on the top side of a pinch roller to individually raise pinch rollers that are not in use. To return a pinch
roller to its original position, push up the grip on the bottom side while supporting the grip on the top side.
IMPORTANT
Gripping both the top and bottom grips of a pinch roller at the same time may break the grips.
Loading the Material
Basic Settings and Operations 21

Roland Camm-1 GR2-540 Specifications

General

Connectivity	USB 2.0, Ethernet
Cutting Method	Media-moving method
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Power Requirements	AC 100 to 240 V ±10%, 50/60 Hz
Cutting Width	54 inches
Maximum Cutting Speed	1, 485 mm/s
Software Resolution	0.025 mm/step
Weight	187 lbs
Usable Tools	Cutting blade, plotting pen
Distance Accuracy	±0.2% or 0.3 mm (0.012 in), whichever is greater
Repeatability Accuracy	±0.1 mm
Alignment Accuracy for Print & Cut	±0.04 inches
Operating Temperature	41-95°F (5-35°C)
Operating Humidity	35 to 80% RH (non-condensing)
Weight (with stand)	187 lbs
Blade Type	Roland CAMM-1 series blades
Resolution	0.025 mm/step
