Viewing System Information
Check the system information, including the firmware version, IP address, and MAC address.
Procedure
1. Press [MISC].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
2. Press [▶] several times to display the screen shown below.
Display screen Information
IP address assigned by the DHCP server on the network
IP Address
Select: OK:ENTER
Manually set a static IP address for the cutting machine
MAC address of device
Set communication
Select: OK:ENTER
Set the communication speed of the RS-232C cable
Firmware: X.XX
FPGA: XX.XX
Firmware version
Device serial number
MEMO
For information on how to set up a network, see the Installation Guide.
3. Press [ON/OFF LINE] to go back to the original screen.
Configuring and Viewing Environment Settings
Basic Settings and Operations 17
