Extending the Cutting Area in Specified Directions
Extending the cutting area allows for maximum material usage.
Procedure
1. Press [MISC].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
2. Press [▶] several times to display the screen shown below.
Paper Saving Mode
Select: OK:ENTER
3. Press [ENTER].
The current setting is displayed.
4. Press [▲] or [▼] to select the mode of extension.
Both Unexpamded Mode
Change: OK:ENTER
Do not extend the length (X direction) or width (Y direc-
tion)
Length Expanded Mode
Change: OK:ENTER
Extend the length (X direction)
Width Expanded Mode
Change: OK:ENTER
Extend the width (Y direction)
Both Expanded Mode
Change: OK:ENTER
Extend both the length (X direction) and width (Y direc-
tion)
5. Press [ENTER] to confirm your entry.
The screen shown below appears. If material is loaded, the size must be measured again. Raise
the lever and measure the material.
Place Media And Then
Lower Down The Lever
MEMO
• Default setting: "Both Unexpanded Mode"
• Extended range:
Width: 20 mm (0.79 in.)
Length (feed direction): 50 mm (1.97 in.)
RELATED LINKS
・ P. 31 "Measuring the Material Size"
Using the Material with Minimal Waste
132 Other Operations and Settings
