You can set the curves in cutting data sent to this machine to be smooth. Normally, the smoothing
function is set to "Enabled", but in cases where you are cutting small text or intricate shapes, set the
smoothing function to "Disabled" in order to prevent the corners from being cut rounded. We recom-
mend that you also set this to "Disabled" when you need to increase productivity regardless of quality.
Procedure
1. Press [TOOL SELECT].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
2.
Press [▶] several times to display the screen shown below.
Set Smoothing Cut
Select: OK:ENTER
3. Press [ENTER].
The current value is displayed on the screen.
4. Press [▲] or [▼] to set this to "Enabled".
5. Press [ENTER] to confirm your entry.
6. Press [ON/OFF LINE] to go back to the original screen.
MEMO
Default setting: [Enabled]
Smoothly Cutting Arcs and Other Curves
(Smoothing)
Optimizing the Output Quality 115
