Adjusting the Roll Material Feed
Adjust the roll holder so it tracks the rotation of the roll material, ensuring the smooth feeding of this
material.
Procedure
1. Turn the damper ( ) to adjust how much the roll holder rotates.
Make adjustments using the adjustment reference sticker ( ) and the damper number ( ) as
references. The roll holder's rotation decelerates as the number of damper ( ) increases.
• If the roll material jumps from the roll holder, turn the damper toward the main unit.
• If the roll material is slack even after adjusting the tension of the roll material, turn the
damper toward the front.
When turning the damper, loosen the screw on the side using a hex wrench.
Loading the Material
28 Basic Settings and Operations
