Roland Camm-1 GR2-540 User Manual

Remove the Material
Remove the material from the cutting machine.
Procedure
1. Raise the lever.
The pinch rollers rise up to release the material.
2.
Remove the material from the front or rear side of the machine.
Separating Only the Cut Area
Procedure
1. Press [▲] or [▼] to feed the material to the position that you want to cut.
2. Move the safe blade along the cutting groove at the front of the cutting machine to cut off the mate-
rial.
Loading the Material
32 Basic Settings and Operations

Roland Camm-1 GR2-540 Specifications

General

Connectivity	USB 2.0, Ethernet
Cutting Method	Media-moving method
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Power Requirements	AC 100 to 240 V ±10%, 50/60 Hz
Cutting Width	54 inches
Maximum Cutting Speed	1, 485 mm/s
Software Resolution	0.025 mm/step
Weight	187 lbs
Usable Tools	Cutting blade, plotting pen
Distance Accuracy	±0.2% or 0.3 mm (0.012 in), whichever is greater
Repeatability Accuracy	±0.1 mm
Alignment Accuracy for Print & Cut	±0.04 inches
Operating Temperature	41-95°F (5-35°C)
Operating Humidity	35 to 80% RH (non-condensing)
Weight (with stand)	187 lbs
Blade Type	Roland CAMM-1 series blades
Resolution	0.025 mm/step
