Corners and edges are cut cleanly when the material is cut with the tool blade facing the direction of
travel. This setting is effective for cutting intricate designs, small text, or thick materials. We recom-
mend that you set this to "Enabled" for normal use.
Procedure
1. Press [TOOL SELECT].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
2. Press [▶] several times to display the screen shown below.
Set Tangential Mode
Select: OK:ENTER
3. Press [ENTER].
The current value is displayed on the screen.
4. Press [▲] or [▼] to set this to "Enabled".
5. Press [ENTER] to confirm your entry.
6. Press [ON/OFF LINE] to go back to the original screen.
MEMO
Default setting: [Disabled]
Cutting Small Text and Complex Graphics Clean-
ly (Tangential)
114 Optimizing the Output Quality
