Setting Up Perforated Cutting from the Operation Panel
You can set up perforated cutting on the operation panel.
Procedure
1. Press [MISC].
If material is loaded, press [ON/OFF LINE] to switch to offline mode.
2. Press [▶] several times to display the screen shown below.
The current setting is displayed.
Die/Kiss Cut : OFF
Select: OK:ENTER
3. If "Die/Kiss Cut" is "OFF", press [▲] or [▼] to switch "Die/Kiss Cut" to "ON".
4. Press [ENTER].
5. Set the cutting lengths for "Die Cut" and "Kiss Cut".
Die/Kiss Cut:
Length: XX / XX mm
(1) Press [◀] to select "Die Cut". Press [▶] to select "Kiss Cut".
(2) Press [▲] or [▼] to change the value.
6. Press [ENTER].
7. Set the blade forces for "Die Cut" and "Kiss Cut" on the following screen.
Die/Kiss Cut:
Force:
XXX g XXX g
(1) Press [◀] to select "Die Cut". Press [▶] to select "Kiss Cut".
(2) Press [▲] or [▼] to change the value.
8. Press [ENTER].
9. Press [ON/OFF LINE] to go back to the original screen.
MEMO
Default setting: "OFF"
Cutting length setting range (Die Cut/Kiss Cut): 0.1 to 100 mm/0.1 to 100 mm (changeable in 0.1 mm incre-
ments)
Blade force setting range (Die Cut/Kiss Cut): 5 to 600 gf/5 to 600 gf (changeable in 5 gf increments)
Cutting Perforated Lines
Other Cutting 89
