Line Modules Booksize
4.6 Basic Line Modules with internal air cooling
Booksize Power Units
240 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Table 4- 49 Meaning of the LEDs on the Basic Line Module
Off Off The electronics power supply is missing or outside the
permissible tolerance range.
–
Green -- The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
–
Orange The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is present.
–
Red The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is outside the permissible tolerance
Check the line supply
voltage.
DRIVE-CLiQ communication is being established.
Red -- This component has at least one fault.
The LED is activated regardless of whether the
corresponding messages have been reconfigured.
Resolve and acknowledge
the fault.
Green/
-- Firmware is being downloaded. –
Green/red
(2 Hz)
-- Firmware download has been completed. The system
waits for POWER ON.
Carry out a POWER ON.
Green/orange
or
red/orange
-- Component recognition via LED is activated
1)
.
Both options depend on the LED status when
component recognition is activated.
–
1)
See SINAMICS S120/S150 List Manual for the parameters to activate the recognition of components via LED
Danger of death when live parts of the DC link are touched
Irrespective of the state of the LED "DC LINK", hazardous DC link voltages can be present.
This means the touching of live parts can result in death or serious injury.
• Observe the warning information on the component.
