6.5 Motor Modules Liquid Cooled
Booksize Power Units
482 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
6.5.7
Technical data
Table 6- 52 Technical data for Motor Module Liquid Cooled 200 A
Liquid Cooled
6SL3125-1TE32-0AAx
Output current
Rated current (I
n
)
Base-load current (I
H
)
Intermittent duty current (I
S6
) 40%
Peak current (
Imax
)
A
ACrms
A
A
ACrms(Is6)
A
ACrms(Imax)
200
141
230
282
Output voltage
V
ACrms
0 … 480
DC-link current I
d max
A
DC
200
DC-link voltage (up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
3995
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20,4 … 28,8)
Electronics current drawn
at 24 VDC
A
DC
0,85
Current carrying capacity
DC-link busbars
24 VDC busbars
A
DC
A
DC
200
20
Unit rating
2)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
107
76
Total power loss
(including electronics losses, see Power
loss tables (Page 781))
W 2070,4
Max. pulse frequency
without derating
with derating
kHz
kHz
4
16
Max. ambient temperature
without derating
with derating
° C
° C
40
55
Max. coolant temperature
without derating
with derating
° C
° C
45
50
Max. permissible heat sink temperature
° C
79 (70% derating)
Rated flow rate
for water at 70 kPa pressure drop
(for other coolant (Page 795))
l/min 8
Volume of liquid internal
ml
100
Weight
kg
21
1)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
2)
Rated power of a typical standard induction motor at 400 V 3 AC.
